* Type: 10GPON XGPON Power Meter
* Use: FTTX
* Polarization loss: <±0.25dB
* Linear:±0.1dB
* Calibrated wavelength: 1270/1310/1490/1550/1577nm
* Optical connector: FC/UPC(SC)

VFL:
* Wavelength: 650±20nm
* Output Power: >10mW
* Mode: CW/1Hz/2Hz
* Connector: FC/SC/ST

Description

NK5O3 can measure the power of GPON/EPON and XGPON/XG SPON network uplink and downlink signals,including uplink 1270/1310nm signal,and downlink 1490/1550/1577nm signal. It integrates 5 functions,such as VFL, RJ45 Cable sequence, Iength and tracking test. It can simultaneously test and judge the optical power value of voice, data and video signals.It can measure all PON signals, and measure each wavelength separately. It is an ideal choice for PON network engineering, construction and maintenance. It has the function of "Pas/Fail" optical fiber authentication detection by setting different thresholds corresponding to different wavelengths, which ensures that service providers can improve the system performance by verifying network connectivity.
